Lightning strikes are among nature’s most powerful forces, capable of causing extensive damage to outdoor lighting systems, particularly LED lights. Despite their efficiency and durability, LED lights are vulnerable to electrical surges generated by lightning, which can compromise their performance and longevity. But this was not always common knowledge.
Back in 2007/8, when LEDs for low-voltage outdoor lighting were emerging onto the market, their installation flexibility looked promising. There were going to be some bumps in the road, but as the years passed, it became clear that LEDs were here to stay, and it was time to make the transition. Fast forward to today, and the technology has vastly improved to the point where LED lights far outperform old halogen lamps, and their failures are much fewer.
But this didn’t last, as over the years, we observed failures and/or partial failures where only half of the LED diodes would be lit or very dim. We attributed this to a manufacturing or component defect in the early days of LEDs. Later, we noticed a strange phenomenon that puzzled us until it hit us like a bolt of lightning right in between the eyes—pun intended.
This guide explores why LED luminaires are at risk of direct lightning strikes, how to protect them, and the role of surge protection in ensuring outdoor safety.
Why Are LED Lights Vulnerable to Lightning Strikes?
LEDs, though energy-efficient and long-lasting, rely on intricate electronic components to function properly. These components, such as drivers and circuitry, are sensitive to voltage fluctuations. When lightning strikes, it produces transient surges that travel through the electrical system, overwhelming these delicate components. This leads to failures like dimming, partial burnout, or complete damage.
An observed phenomenon reveals that even indirect lightning strikes—such as those impacting nearby trees—can send surface currents into buried copper wiring, acting as a pathway to LED systems. This makes outdoor LEDs particularly vulnerable to electrical overstress (EOS)—which is too much voltage, current, or power—caused by lightning.
To compound the issue, repairing or replacing LED fixtures damaged by lightning can be a costly endeavor. Beyond the financial implications, there’s the inconvenience of downtime, especially in commercial or public spaces where outdoor lighting serves a functional or safety-critical role. Putting in place proper protective measures not only preserves the operational integrity of the system but also prevents unexpected costs and disruptions.
Understanding these vulnerabilities highlights the importance of proactive protection measures. By addressing these risks, you can ensure your outdoor LED lighting systems remain reliable, even during severe weather conditions.
Doing a Project and in Need of Outdoor Lighting?
Understanding Power Surges: Causes and Effects
Power surges occur when there’s a sudden increase in electrical voltage, exceeding the normal operating range. Lightning strikes are one of the primary causes, but other factors include utility grid switching, faulty wiring, or sudden restoration of power after outages.
For LED lights, voltage surges can result in:
- Complete burnout: The internal circuits of LEDs are fried, rendering them inoperable.
- Partial failure: Some diodes dim or fail, leading to uneven lighting.
- Shortened lifespan: Repeated exposure to minor surges degrades components over time.
Surges can lead to immediate damage, such as burnt-out circuits, or gradual wear and tear that shortens the lifespan of electronic components. Understanding the causes and effects of voltage surges is critical to preventing damage and maintaining your lighting system’s functionality. This ultimately prevents frequent replacements, saving you time and money.
The Role of Surge Protection in Outdoor Lighting
Surge protection is a critical component in safeguarding your outdoor LED lighting systems. It acts as a buffer, absorbing excess voltage and redirecting it safely to the ground, preventing damage to connected equipment and other sensitive components.
Surge protection devices (SPDs) play a crucial role in defending LED luminaires from electrical overstress. These devices work by diverting excess voltage away from sensitive electronic equipment or components, ensuring they remain within a safe operating range.
Without proper surge protection, outdoor lighting systems are exposed to several risks. These include, but are not limited to, expensive replacements for damaged components, increased maintenance costs, and safety hazards caused by malfunctioning lights.
Investing in surge protective devices not only safeguards your LEDs but also enhances their longevity and performance.
Types of Surge Protection for Outdoor LED Lights
Fortunately, there are a few protection measures you can put in place to safeguard your LEDs from voltage spikes. These protection solutions range from system-wide to those specifically focused on LED lighting systems. Here are a few to consider:
Whole-system Surge Protection Devices
These SPDs are designed to protect the entire lighting system from voltage spikes. These are typically installed at the main power source and provide a broad layer of defense against high-voltage surges. They’re highly effective, deflecting electrical shocks up to 40,000 amps.
LED-specific Surge Protection
LED-specific SPDs are tailored to the unique needs of LED lighting systems. These compact devices can be integrated into individual fixtures or at key points in the circuit to shield LEDs from transient voltages.
An LED-specific SPD protects the light from power surges by diverting the surge’s energy to the ground. Excellent surge protective devices should address both common mode and differential mode surges.
Grounding and Shielding Solutions
Grounding and shielding are essential components of an effective surge protection strategy. By connecting the lighting system to an 8-foot ground rod, excess current from a lightning strike is safely discharged into the earth, preventing it from reaching LED components.
Shielding techniques, such as using surge-suppressive cables, further minimize exposure.
How to Safeguard Outdoor LED Lights from Lightning Strikes
Protecting your LED luminaires requires a combination of proper planning, installation, and continuous maintenance. Take a look at these four steps to get you on the right path:
- Install Surge Protection Devices (SPDs): Equip your LED lighting systems with high-quality SPDs, like the CLASS 1 surge suppressors introduced by Nightscaping.
- Ground Your System: Ensure your LED lighting systems are properly grounded to redirect dangerous currents.
- Use Compatible Fixtures: Opt for LED fixtures specifically designed to withstand electrical stress.
- Hire Professionals: Work with experienced electricians or lighting designers to ensure correct installation.
Need Tailored Lighting Design for the Outdoors?
Maintenance Tips for Long-Term Protection
Regular maintenance is essential to keep your outdoor lighting system functional and protected at all times. Here are a few ways you can maintain your LED lighting systems:
- Inspect SPDs Regularly: Check your surge protection devices for wear and tear, replacing them as needed. You’ll avoid overhaul replacements, which can be costly.
- Schedule System Checks: Have your lighting system inspected annually by a certified professional. This allows you to detect potential issues before they arise.
- Upgrade When Necessary: Replace outdated or underperforming electrical equipment or components with modern, surge-resistant alternatives.
- Monitor for Signs of Damage: Look for dimming, flickering, or partial burnout in your LEDs—these could indicate exposure to surges.
Keep in mind that lightning strikes are not the only cause for surges; common electrical faults or interruptions in electrical supply could also cause damage. By keeping a close eye on your lighting system, you can also put in place LED protection measures against other issues.
Lights Not Working After a Lightning Strike?
Hire our experts:
FAQ: Protecting Outdoor LED Lights from Lightning Strikes
You may still have some lingering questions about power surge damage on LED lights. So, here are a few short answers to the most common questions.
What Happens to LED Lights During a Lightning Strike?
When a lightning strike occurs, the surge of electricity can overload the sensitive circuits in LED luminaires, causing them to dim, partially fail, or burn out completely.
Do All Outdoor Lights Need Surge Protection?
Yes, all outdoor lighting systems benefit from surge protection. While LEDs are more susceptible to surges, even traditional lights can be damaged by voltage spikes.
What Is the Cost of Installing Surge Protectors?
The cost varies depending on the system’s complexity. A basic SPD installation may cost around $100–$300, while advanced solutions with grounding systems can exceed $500.
Can Surge Protectors Fail During Severe Storms?
Yes, surge protectors have limits. A direct lightning strike or an exceptionally high surge may overwhelm the device. However, high-quality SPDs significantly reduce the risk of failure.
How Often Should Surge Protectors Be Replaced?
SPDs typically last 3–5 years, but their lifespan depends on the frequency and intensity of surges. Inspect them regularly and replace them at the first sign of wear.
Conclusion
LED lights have revolutionized outdoor illumination with their efficiency and durability, but their sensitive electronics make them vulnerable to lightning surges. Investing in surge protection devices, proper grounding, and regular maintenance can protect your lighting system from damage, ensuring it remains reliable for years to come.
For peace of mind and the safety of your outdoor LED luminaires, consider integrating surge protection into your system today. Contact a trusted expert to safeguard your investment against the unpredictable forces of nature, and don’t forget to hire Lighthouse Outdoor Lighting for maintenance services.
